Pallet Rack Identification Guide: Know What You’re Working With
10:17

Who Manufactures Your Warehouse Racking and Why It Matters

In warehouse operations, not all pallet racking is created equal, and not all of it is clearly labeled. Legacy installations, inherited systems from acquisitions, and multi-vendor layouts can make identifying the racking’s original manufacturer challenging, yet knowing the manufacturer of your rack is critical for part replacements and repairs.

We’ve included a pallet rack identification chart to help you visually compare North America’s most common (and less common) pallet rack systems and manufacturers. Whether upgrading or replacing components, recognizing your rack type prevents costly mismatches and potential safety hazards.

Most Common Pallet Rack Manufacturers

Which Rack Brand Do You Own?

Advanced Storage Systems logo – North American pallet rack manufacturer specializing in industrial shelving, racking, and storage solutions. Cubic pallet rack logo – manufacturer of warehouse racking systems Dexion pallet rack logo – manufacturer of industrial shelving and storage systems
Frazier Industrial Company logo, structural pallet racking manufacturer Husky Rack & Wire logo – U.S. manufacturer of teardrop pallet racking and wire security partitions Interlake Mecalux rack manufacturer logo — compatible with Damotech repair kits
Konstant logo – Canadian manufacturer of pallet racking systems North American Steel logo – Canadian manufacturer of pallet racking systems, including roll-formed and structural warehouse storage solutions. Nucor logo – U.S. steel manufacturer and parent company of Hannibal Industries, known for structural pallet racking systems.
Penco logo – manufacturer of industrial pallet racking, shelving, and storage solutions Republic Storage Products logo — manufacturer of pallet rack systems Redirack logo — Canadian pallet rack manufacturer known for square punch uprights
Rapid Racking logo – supplier of boltless pallet racking, shelving, and warehouse storage systems Ridg-U-Rak logo – U.S. manufacturer of teardrop pallet racking and structural rack systems Space Aid logo – Canadian manufacturer of teardrop pallet racking and warehouse storage systems
Speedrack Products Group logo — manufacturer of pallet racking systems Steel King logo — U.S. manufacturer of high-capacity pallet racking and boxed uprights UNARCO logo – U.S. manufacturer of teardrop, T-Bolt, and Sturdi-Bilt pallet racking systems

Pallet rack systems may look similar, but each manufacturer builds in unique features.

It’s important to distinguish between rack style and rack brand. For example, teardrop racking, easily identified by its rounded tear-shaped punch holes, is widely used across North America. Brands like Interlake Mecalux, Ridg-U-Rak, Speedrack, Steel King, Hannibal, and Husky pallet racking each manufacture variants of this style, and many are not cross-compatible, especially regarding beam hardware.

On the other hand, structural pallet racking uses hot-rolled C-channel steel with bolted connections. It offers superior rigidity but requires more planning to modify or replace.

Still not sure what you’re working with? Damotech can repair it regardless of brand, age, or style.

Damotech Infographic Column Repair vs. Replacement



Why Identifying Rack Manufacturers Is Hard

Identifying your racking brand sounds simple—but it’s not. Here’s why:

  • Missing ID plates are common.
  • Inherited systems from previous tenants or expansions add mystery.
  • Discontinued brands, like Triple A, Frick Gallagher, and Artco, are no longer made.
  • Mixed inventories often include Interlake pallet racks, Frazier racking, and custom-built racks.
  • Lookalike punch patterns can differ in spacing, gauge, and clip style.

Even if you think you’ve identified a rack, using the wrong part can cause misalignment—or worse, a safety hazard.

That’s why Damotech doesn’t rely on identification labels. We rely on precise measurements and engineered solutions.

Two images side-by-side. On the left, a section of a warehouse rack with significant impact damage. On the right, the same rack after a professional repair, appearing fully functional.


Damotech Doesn’t Rely on Rack Brand Alone

When rack damage happens, knowing the brand isn’t required.

Our process starts with the damaged upright. Damotech’s experts measure the column, evaluate the damage, and analyze how loads are distributed. We then design a repair solution that matches or exceeds the original structural integrity.

Every kit is made-to-measure, bolt-on (no welding), and typically installed in under an hour. It is backed by ANSI and OSHA compliance and often includes a lifetime warranty. Replace only what’s damaged—stay safe, stay efficient.

Are you unsure whether to repair or replace a damaged upright? Use our calculator to see your 10-year return on investment (ROI) when repairing damaged uprights with Damotech kits versus replacing them with new OEM uprights.


Identifying Upright Punch Styles on Pallet Rack Columns

Pallet rack uprights are punched with holes—called punch patterns—that allow beams to connect to the columns. While these holes vary in size, shape, and spacing between manufacturers, three punch types dominate most rack systems in North America:

  • Teardrop: The most common clip-in style, known for its rounded, droplet-shaped holes. Popular among Interlake, Husky Rack & Wire, and Ridg-U-Rak systems.
  • Rectangular or Square: These are found in Redirack, Republic, and other bolt-in systems. The holes are evenly spaced for secure bolted connections.
  • Slotted or Keyhole: A mix of round and oblong openings—often seen in Speedrack or older Rapid Rack designs.

These punch styles allow for fast installation and modular reconfiguration, especially in roll-formed systems. Structural racking, by contrast, uses bolted hardware and C-channel steel, offering higher impact resistance but requiring more effort to modify.

Preview: Can You Identify These Pallet Rack Uprights?

Here’s a quick look at four common OEM rack columns.

Arcan Upright

Arcan

Frazier Racking Upright

Frazier

Interlake Pallet Rack Upright

Interlake HD

Unarco Rack Upright

Unarco

Can you recognize yours? No worries if you don’t. Download the complete Pallet Rack Identification Guide and scroll through the full visual chart of 40+ OEM rack styles.

OEM Pallet Rack Visual Guide Unsure of your racking brand? Scroll through our visual guide to identify your rack style.


Damotech Repairs Any Rack.

Rack Brand Unknown? No Problem.

No identification label? No problem. Damotech custom engineers repair kits for every system, from standard teardrop designs to obscure or discontinued profiles.

Even when your racking system lacks identification labels or documentation, Damotech restores it safely and to full compliance. We don’t depend on OEM part numbers or compatibility guesses. Our engineers inspect the damage, take precise measurements, and build repair kits that match your upright, restoring capacity without warehouse disruption.

Damotech has repaired virtually every rack style in use today, from structural C-channels to roll-formed uprights. Each kit is engineered to match the original load capacity, comply with ANSI MH16.1, and install quickly with minimal to no unloading.

If the manufacturer can’t be identified, we can still repair it. That’s what we do.



Damotech Repairs These Rack Brands—and More

We repair every major rack type in North America. Below are just a few, grouped by style:

Teardrop Racks

  • Interlake, Unarco, Ridg-U-Rak, Husky, Speedrack

Each manufacturer designs its own variation of these punch patterns. Damotech’s custom repair kits fit every style—there is no guessing or mismatching.

Bolt-In / Rectangular Punch Racks

  • Redirack, Konstant, Republic, Rapid Rack, Pedler (Maxi Rack)

Square or rectangular punch-outs differ in spacing and beam fit. Damotech measures your damaged upright and custom engineers a solution that matches the original load capacity—no sourcing of obsolete hardware needed.

Structural & C-Channel Racks

  • Frazier, Frick Gallagher, Sturdi-Bilt

Built with hot-rolled C-channel steel, these are strong but hard to modify. Damotech repairs restore their structural integrity, without complete replacement or downtime.

Discontinued Racking Systems (or Unknown)

  • Triple A, Artco, M-I (D’Altrui), Custom Fabrications, Paltier, Hiline, Amerlock, Mirack, Webb Lock, Palmer Shile

No manufacturer? Not a concern. We engineer safe, compliant repairs for most pallet rack systems.

Have damaged pallet racks in your warehouse?
We’ll send a Damotech expert to your facility at no cost.
On-site visit by a certified rack specialist
Expert advice on how to fix the damage
Detailed quote with engineered repair recommendations
Request your FREE rack assessment →


The Damotech Process: From Rack Damage to Certified Repairs

Here’s how we turn damaged racks into safe, code-compliant systems:

  • On-site rack damage assessment and measurements
  • Structural analysis of uprights and damage
  • Custom repair kit design
  • Fast, certified installation
  • ANSI & OSHA compliance guaranteed

All without unloading your racks. Safer, faster, and far more cost-effective than full rack replacement. Take a short quiz to find out how safe your warehouse is.


Still Can’t Identify Your Rack’s Manufacturer?

That’s where Damotech can help.

Even if your rack is bent or unknown, Damotech can repair it. We’ve assessed and repaired tens of thousands of pallet racks. We don’t rely on identification labels. We rely on engineering.

Our repairs are certified, load-bearing, and more cost-effective than OEM replacement or part matching. Unidentifiable doesn’t mean unrepairable, not for us.

📌 Case in Point: One national chain saved over $10 million annually in maintenance costs by repairing thousands of rack uprights with Damotech—no OEM was needed.

Case study on National Accounts


Ready to Make a Damaged Rack Safe Again?

Don’t risk mismatched parts or wait months for OEM replacements. Choose the faster, safer path.

  • Avoid compatibility mistakes
  • Skip manufacturer delays
  • Stop overpaying for full replacements

🎯 Schedule a Free Rack Damage Assessment

ASK A RACK EXPERT Get answers quickly on any rack safety related topic.


Frequently Asked Questions about Rack Manufacturers

Which pallet racking brands are no longer being manufactured?
FAQ arrow

Some pallet rack brands have been discontinued, making it harder to find replacement components. Examples include:

  • Paltier
  • Hiline
  • Amerlock
  • Mirack
  • Frick Gallagher
  • Webb Lock
  • Palmer Shile

If your warehouse racking includes any of these names or rack systems without labels that look unfamiliar, you may be working with a legacy or unsupported rack brand. Fortunately, Damotech specializes in repairing all rack systems, even those that are no longer made.

Can I mix pallet racking brands or beam types?
FAQ arrow
Mixing components from different rack manufacturers is not recommended per RMI. Even if punch patterns look similar (like teardrop), slight spacing, depth, or gauge differences can cause misalignment and serious safety hazards. Damotech repairs fully restore your racks’ load capacity and replicate the original brace design configuration so that structural behaviors are maintained.
What should I do if my pallet rack brand is no longer manufactures?
FAQ arrow
If your damaged rack system is discontinued, don’t panic. Damotech engineer repair kits are compatible with any rack manufacturer. Book a free rack damage assessment, and we’ll recommend the safest path forward.
Do I need to replace a whole upright if it’s damaged?
FAQ arrow
No, with Damotech’s engineered repair kits, you can repair just the damaged portion of an upright, without unloading or replacing the full frame. Our repair solutions meet ANSI and OSHA compliance, and a lifetime warranty backs our DAMO PRO. This makes our repairs faster, safer, and more cost-effective than full replacements.
What’s the difference between roll-formed and structural pallet racking?
FAQ arrow
Roll-formed racking is made from cold-rolled steel and typically uses clip-in beams (like teardrop or slotted styles). Structural racking is made from hot-rolled C-channel steel and uses bolted beam connections for higher strength. Damotech offers custom repair solutions for both styles.
